Top Loading

TK 5315

Top Load Tower

The lifting tower T 103 is designed to lift vertical loads up to 150 Kg and 5,3 m. Comprised of 3 extensible steel profiles lifted by a high strength steel cable. Safety mechanism based on steel pins that lock the tower into the desired height automatically. Legs equipped with non-slip rubber plates. The entire system is operated with a manual winch. T 103 offers the perfect balance between varsatility, load capacity, ease of transportation and features.

Maximum Load
150kg/330.7lb
Folded Height
1.8m/5.91ft
Maximum Height
5.3m/17.39ft
Weight
45kg./99.21lb.



Share on

Features

  • Great versatility.
  • Wire Drive.
  • Levelable leg system.
MaterialSteel
Folded Height1,8 m / 5,91 ft
Extended base dimensions2,1 x 2,1 m / 6,89 x 6,89 ft
Folded base dimensions0,37 x 0,37 m / 1,18 x 1,18 ft
Maximum height5,3 m / 17,39 ft
Minimun height1,8 m / 5,91 ft
No. of sections4
Minimum Load25 Kg / 55,12 lb
Max load (mechanism mode)150 Kg/ 330,7 lb
Winch500 Kg / 1102,3 lb
Cable diameter4 mm / 0,16 in
Noise Emission72 dB
Compatible accessoriesATCMOS / ATCMOB / ATCLTS / ATC6FS / ATC29S / ATCBAS
Security systemsSelf locking safety pins
Standards and CertificationsCE, DGUV, BGV C1, BGG 912
Weight45 Kg / 99,21 lb
Unfolded base diameter2,05 m / 6,73 ft
  Certificate		Download
  Certificate		Download
  Manual		Download
  Datasheet		Download

So far, there are no questions related to this product.

Register to be able to ask a question about this product.

I accept terms and conditions regarding the treatment of my data.Make the question

Related

  • TKA 351
    Universal truss bracket for all models of top-loading towers.
  • TKA 351B
    Universal truss bracket for all models of top-loading towers.
  • TKA 356
    Adapter for six spotlights to top-loading towers.
  • TKA 359
    Adapter for top-loading towers 35 to 29 mm diameter.

Alternatives

  • TK 5322
    Top load tower. Number of profiles: 4. Maximum load: 225 Kg. Maximum height: 5,3 m.

Spareparts

  • CAB-500
    Winch with a maximum load of 500 kg for FT6520, FT5323, T103 and T104 towers.
  • P-2
    Leg for T102 and T103 towers.
  • RUEDA 0403
