TA21 W

New Products!

Stage deck

Stage deck with great versatility and the highest success guarantee. Birch plywood 21 mm with WISA® weather-resistant phenolic gluing according to EN-314-2/class 3. Maximum load: 750 Kg/m². Profiles in silver colour. Available in 2x1, 1x1, 2x0.5 and 1x0.5 metres. (FEET NOT INCLUDED. SOLD SEPARATELY)



Share on

Features

  • Highest quality of materials.
  • Availability of custom stage decks.
  • Other profile colours on request.
Maximum Load750 Kg/m²/ 102,41 lb/sq ft
DurabilityClass 3 (sealed lining and edges)
AbrasionDIN 53799 (1/1986) / EC 438-2:1991
EnvironmentPEFC ST 2002:2013 and PEFC ST 2001:2008.
PanelBirch plywood 21 mm with WISA® weather-resistant phenolic gluing according to EN-314-2/class 3.
MaterialAluminum 6082 T6
Gluing qualityClass 3 EN 314-2
Reaction to fireEN 13986:2004 +A1:2015
Water vapor permeabilityWet cup 90, Dry cup 220 (uncoated)
Board regulationsEN-314-2/Class 3, EN 636
Regulations of the complete moduleDIN 4112-4113
Module dimensions2 x 1 x 0,0978 m, 1 x 1 x 0.0978 m, 2 x 0.5 x 0.0978 m, 1 x 0.5 x 0.0978 m / 6,56 x 3,28 x 0,32 ft
Weight2 x 1 43,4 Kg, 1 x 1 24.86 Kg, 2 x 0.5 26.94 Kg, 1 x 0.5 15 Kg/ 95,68 lb
Length(m)Width(m)Height(m)Weight(kg)
Product2.001.000.1043.40
  Certificate		Download
  Manual		Download

So far, there are no questions related to this product.

Register to be able to ask a question about this product.

I accept terms and conditions regarding the treatment of my data.Make the question

Related

  • TA21 PTN
    Extendable leg 60x60 mm with leveller. For TA 21 and TA 25 stage decks.
  • TA21 PF
    60x60 cm fixed leg. For TA 21 and TA 25 stage decks.
  • TA21 PFN
    Fixed leg 60x60 mm with leveller. For TA 21 and TA 25 stage decks.
  • TA21 PTT
    60x60 cm extensible leg. For TA 21 and TA 25 stage decks.
